AV-A12
| Bominal Power Rate |
37KW |
| Max. Continuous Pressure |
360-410Mpa |
| Max. Water Discharge |
3.7L/min |
| CNC system |
PLC(Omron) |
| Cutting Water Inletpressure |
>0.5Mpa |
| Cooling Water Inletpressure |
>0.1Mpa |
| Max. oil pressure |
20Mpa |
| Accumulator Volume |
1L |
| HighPressure Outlet Connections |
M16X1.5 |
| Length |
1745 |
| Width |
1045 |
| Height |
1350 |
| Weight |
1200Kg |
| Lp Low Pressure Filter |
10um |
